W07: Pneumatic Wiper, Scraper Seals Manufacturers, Suppliers, Exporters

Max Spare : W07

Profile : Wiper Seals

Details :

E07 is a pneumatic rod/wiper seal performs both sealing and wiping function. It has improved seal-lip design for better sealing and scraping performance. Very good protection against dirt ingress. The standard material is Polyurethane it offers exceptional wear resistance and extremely high operating performance. Special lip design for pneumatic application to maintain lubricating film and minimize friction.

MATERIAL

Pneumatic Cylinders.
Pneumatic Valves.
Short-stroke cylinders.

OPERATING CONDITIONS

Temperature Range	:	-30° C to + 100° C
Pressure	:	16 Bar
Speed	:	1.0 m/s

SURFACE ROUGHNESS

Static	:	1.6 µmRa
Dynamic	:	0.4 µmRa

COMPATIBILITY

Dry and oil-free air.

APPLICATION

Polyurethane 92 Shore A.

FEATURES

Dual function - both sealing and wiping.
Extreme wear resistance.
Long service life.
Smooth running due to optimum lubricant-retaining sealing lip geometry.
Installation in open housings.
Low compression set.
Easy installation.
Low friction.

Part No. :

ID : -

OD : -

Thk :

Mould No. :

Stock Items Only

Part No.	ID	OD	THK	Material	Mould No.
W07008CF01	8.00	14.00	7	PU	WPH-2657
W07010CF02	10.00	16.00	7	PU	WPH-2656
W07010CF01	10.00	18.00	10.40	PU	WPH-2377
W07010Y701	10.00	18.00	10.70	PU	WPH-298
W07012L504	12.00	19.00	10.40	PU	WPH-2897
W07012L503	12.00	20.00	10.4		WPH-394
W070126704	12.00	20.00	10.40	FKM	WPS-2230
W07012L408	12.00	22.00	10.40	PU	WPH-1972
W07012CF02	12.00	22.00	10.40	PU	WPH-2827
W070126701	12.00	22.00	10.40	FKM	WPS-2227
W07012L402	12.00	22.00	10.7	PU	WPH-1320
W07012L402	12.00	22.00	10.7	PU	WPH-393
W07012Q201	12.00	22.00	10.70	PU	WPH-1982
W07012L502 (Stock Item)	12.00	22.00	10.70	PU	WPH-2053
W070126703	12.00	22.00	10.70	FKM	WPS-404
W070121102	12.00	22.00	10.70	NBR	WPS-6307
W07013CF01	13.00	26.00	10.70	PU	WPH-2878
W07014CF01	14.00	24.00	10.40	PU	WPH-535
W07014L501	14.00	24.00	10.7	PU	WPH-1285
W07016L507	16.00	23.00	4.90	PU	WPH-220
W070165903	16.00	26.00	10.4	PU	WPH-392
W07016L503	16.00	26.00	10.40	PU	WPH-1983
W070165903A	16.00	26.00	10.40	PU	WPH-577
W070166601	16.00	26.00	10.40	FKM	WPS-2217
W070166703	16.00	26.00	10.50	FKM	WPS-6539
W07016L501 (Stock Item)	16.00	26.00	10.70	PU	WPH-1984
W070166702	16.00	26.00	10.70	FKM	WPS-3302
W07016X401	16.00	30.00	10.70	PU	WPH-2663
W07018L401	18.00	28.00	10.40	PU	WPH-1973
W07018L503	18.00	28.00	10.70	PU	WPH-1577
W07018L503 (Stock Item)	18.00	28.00	10.70	PU	WPH-2297
W070186702	18.00	28.00	10.70	NBR	WPS-403
W07020L502	20.00	30.00	10.40	PU	WPH-2353
W07020CF01	20.00	30.00	10.40	PU	WPH-2655
W07020Y701	20.00	30.00	10.40	PU	WPH-3033
W070206705	20.00	30.00	10.40	FKM	WPS-6730
W07020L503	20.00	30.00	10.5	PU	WPH-826
W070206707	20.00	30.00	10.55	FKM	WPS-1025
W07020L404	20.00	30.00	10.7	PU	WPH-1327
W07020L503	20.00	30.00	10.7	PU	WPH-181
W070206602	20.00	30.00	10.7	FKM	WPS-4459
W07020Q201	20.00	30.00	10.70	PU	WPH-1985
W07020L501 (Stock Item)	20.00	30.00	10.70	PU	WPH-1997
W07020CF03	20.00	30.00	10.70	PU	WPH-2826
W070206706	20.00	30.00	10.70	FKM	WPS-2214
W070206702	20.00	30.00	10.70	FKM	WPS-5215
W070201102	20.00	30.00	11.00	NBR	WPS-1791
W07020L408	20.00	30.00	11.40	PU	WPH-2232
W070206703	20.00	30.00	11.40	FKM	WPS-6662
W07020L507	20.00	30.00	12.70	PU	WPH-384
W070221101	22.00	30.00	5.50	NBR	WPS-1787
W07022L504	22.00	32.00	10.40	PU	WPH-2441
W070226702	22.00	32.00	10.50	FKM	WPS-6485
W07022L503	22.00	32.00	10.70	PU	WPH-2235
W07022L401	22.00	32.00	11	PU	WPH-1110
W07022L403	22.00	32.00	11	PU	WPH-2627
W070226701	22.00	32.00	11	FKM	WPS-3438
W070246501	24.00	30.00	4.30	FKM	WPS-7858
W070256704	25.00	35.00	10.4	FKM	WPS-4641
W07025L509	25.00	35.00	10.40	PU	WPH-1438
W07025CF04	25.00	35.00	10.40	PU	WPH-231
W07025CF01	25.00	35.00	10.40	PU	WPH-2654
W070256703	25.00	35.00	10.7	FKM	WPS-4049
W07025L502 (Stock Item)	25.00	35.00	10.70	PU	WPH-1988
W070255909	25.00	35.00	10.70	PU	WPH-2554
W070251103	25.00	35.00	10.70	NBR	WPS-5456
W070253501	25.00	35.00	10.70	EPDM	WPS-7670
W07025L409	25.00	35.00	11.20	PU	WPH-1731
W07025L501	25.00	35.00	11.20	PU	WPH-2030
W07025L406	25.00	35.00	11.20	PU	WPH-576
W070256602	25.00	35.00	11.20	FKM	WPS-2424
W07025L507	25.00	35.00	11.5	PU	WPH-470
W07256702	25.00	35.00	11.5	FKM	WPS-3740
W070251102	25.00	35.00	11.50	NBR	WPS-5567
W07025L408	25.00	35.00	8	PU	WPH-1658
W07028X401	28.00	38.00	11.50	PU	WPH-2830
W070305904	30.00	40.00	10.40	PU	WPH-700
W070306701	30.00	40.00	10.40	FKM	WPS-7060
W07030L503	30.00	40.00	10.7	PU	WPH-311
W07030L404	30.00	40.00	11.20	PU	WPH-1974
W07032L402	32.00	40.00	10.40	PU	WPH-1659
W07032L403	32.00	40.00	7	PU	WPH-1660
W07032L404	32.00	42.00	10.40	PU	WPH-1975
W07032L504 (Stock Item)	32.00	42.00	10.70	PU	WPH-2268
W07032L401	32.00	42.00	11.2	PU	WPH-189
W070326701	32.00	42.00	11.2	FKM	WPS-1730
W07032L501	32.00	42.00	11.20	PU	WPH-1989
W070358701	35.00	43.00	6.80	PU	WPH-660
W07035CF502	35.00	45.00	10.70	PU	WPH-2676
W070356701	35.00	45.00	10.70	FKM	WPS-6586
W07035CF01	35.00	45.00	11.20	PU	WPH-2658
W07036L401	36.00	46.00	10.70	PU	WPH-2379
W07036CF01	36.00	46.00	10.70	PU	WPH-2677
W07040L403	40.00	50.00	10.40	NBR	WPH-1971
W07040L501 (Stock Item)	40.00	50.00	10.70	PU	WPH-615
W070406703	40.00	50.00	10.70	FKM	WPS-2308
W070407601	40.00	50.00	10.70	AFLAS	WPS-7417
W07040L502	40.00	50.00	11.20	PU	WPH-745
W070406501	40.00	50.00	11.20	FKM	WPS-5125
W070401101	40.00	50.00	11.20	NBR	WPS-5133
W07040L406	40.00	50.00	11.70	PU	WPH-2491
W070402301	40.00	50.00	12.50	NEOPRENE	WPS-6675
W07040L503	40.00	50.00	6.45	PU	WPH-1823
W07045L501	45.00	55.00	10.70	PU	WPH-2296
W07045L403	45.00	55.00	11.20	PU	WPH-2191
W07050L405	50.00	60.00	10.50	PU	WPH-2381
W07050L404	50.00	60.00	11.20	PU	WPH-2300
W070506703	50.00	60.00	11.20	FKM	WPS-7282
W07050CF05	50.00	60.00	12.20	PU	WPH-893
W070506702	50.00	60.00	12.20	FKM	WPS-5928
W07056L401	56.00	66.00	11.20	PU	WPH-2299
W07063CF01	63.00	75.00	13	PU	WPH-2659
W070656701	65.00	77.00	13.00	FKM	WPS-7231
W070726701	72.00	85.00	10.00	FKM	WPS-7166
W070906702	90.00	102.00	13.00	FKM	WPS-520

For customised items please Click here
